YASKAWA J1000 - Duty Mode and Source Configuration

n
Three-Phase 200 V
Normal Duty Heavy Duty
No.
Max Motor Capacity
kW
Rated Output
Current A
No.
Max Motor Capacity
kW
Rated Output
Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0004 0.75 3.5 0004 0.4 3.5
0006 1.1 6.0 0006 0.75 6.0
0010 2.2 9.6 0010 1.5 9.6
0012 3.0 12.0 0012 2.2 12.0
0020 5.5 19.6 0020 3.7 17.5
n
Three-Phase 400 V
Normal Duty Heavy Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
0001 0.4 1.2 0001 0.2 1.2
0002 0.75 2.1 0002 0.4 1.8
0004 1.5 4.1 0004 0.75 3.4
0005 2.2 5.4 0005 1.5 4.8
0007 3.0 6.9 0007 2.2 5.5
0009 3.7 8.8 0009 3.0 7.2
0011 5.5 11.1 0011 3.7 9.2
1.2 Model Number and Nameplate Check
18
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
