YASKAWA J1000 Technical Manual

Table 3.14 Braking Resistor Settings
Parameter Settings
L8-01: Internal Dynamic Braking Resistor
Protection Selection
0: Disabled. The drive will not provide overheat protection. Supply separate
means of overheat protection.
1: Enabled. Braking Resistor is protected from overheat.
L3-04: Stall Prevention During Decel 0: Stall prevention disabled.
8.
Operate the system and verify the required deceleration rate is obtained during dynamic braking or stopping.
3.10 Braking Resistor
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
51
3
Electrical Installation
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
