YASKAWA J1000 - Page 96

The following graphs are for 200 V class drives. Double the values when using a 400 V class drive.
V/f Pattern Examples
Table 5.11
Constant Torque Characteristics, Examples A to D
Example A 50 Hz Example B
60 Hz
(default)
Example C 60 Hz Example D 72 Hz
0
12
200
1.3 2.5 50
16
Voltage (V)
Frequency (Hz)
0
12
16
200
1.5 3 60
Voltage (V)
Frequency (Hz)
0
12
16
200
1.5 3 6050
Voltage (V)
Frequency (Hz)
0
12
16
200
1.5 3 7260
Voltage (V)
Frequency (Hz)
Table 5.12 Derated Torque Characteristics, Examples E to H
Example E 50 Hz Example F 50 Hz Example G 60 Hz Example H 60 Hz
0
8
200
1.3 25 50
35
Voltage (V)
Frequency (Hz)
0
9
200
1.3 25 50
50
Voltage (V)
Frequency (Hz)
0
8
200
1.5 30 60
35
Voltage (V)
Frequency (Hz)
0
9
200
1.5 30 60
50
Voltage (V)
Frequency (Hz)
Table 5.13 High Starting Torque, Examples I to L
Example I 50 Hz Example J 50 Hz Example K 60 Hz Example L 60 Hz
0
12
200
1.3 2.5 50
19
Voltage (V)
Frequency (Hz)
0
13
200
1.3 2.5 50
24
Voltage (V)
Frequency (Hz)
0
12
200
1.5 3 60
19
Voltage (V)
Frequency (Hz)
0
15
200
1.5 3 60
24
Voltage (V)
Frequency (Hz)
Table 5.14 Rated Output Operation, Examples M to O
Example M 90 Hz Example N 120 Hz Example O 180 Hz
0
12
16
200
1.5 3 9060
Voltage (V)
Frequency (Hz)
0
12
16
200
1.5 3 12060
Voltage (V)
Frequency (Hz)
0
12
16
200
1.5 3 18060
Voltage (V)
Frequency (Hz)
5.5 E: Motor Parameters
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
95
5
Parameter Details
