4.6 Other Output Signals
4-49
4.6.3 Rotation Detection Output Signal (/TGON)
This output signal indicates that the servomotor is rotating at the speed set for Pn502 or a higher speed.
(1) Signal Specifications
Note: Use parameter Pn50E.2 to allocate the /TGON signal for use. For details, refer to 3.4.2 Output Signal Alloca-
tions
.
(2) Related Parameter
Set the range in which the /TGON signal is output using the following parameter.
4.6.4 Servo Ready Output Signal (/S-RDY)
This signal is turned ON when the SERVOPACK is ready to accept the Servo ON command.
The /S-RDY signal is turned ON under the following conditions.
• The main circuit power supply is ON.
• No hard wire base block state
•No servo alarms
• The Sensor ON command is turned ON. (When an absolute encoder is used.)
If an absolute encoder is used, the output of absolute data to the host controller must have been completed
when the Sensor ON command is turned ON.
For details on the hard wire base block function, refer to 4.7.1 Hard Wire Base Block (HWBB) Function.
(1) Signal Specifications
Note 1. Use parameter Pn50E.3 to allocate the /S-RDY signal for use. For details, refer to 3.4.2 Output Signal Alloca-
tions.
2. For details on the hard wire base block function and the servo ready output signal, refer to 4.7.1 Hard Wire Base
Block (HWBB) Function.
Type
Signal
Name
Connector Pin
Number
Setting Meaning
Output /TGON Must be allocated
ON (closed)
Servomotor is rotating with the motor speed above
the setting in Pn502.
OFF (open)
Servomotor is rotating with the motor speed below
the setting in Pn502.
Pn502
Rotation Detection Level
Classification
Setting Range Setting Unit Factory Setting When Enabled
1 to 10000
1 min
-1
20 Immediately Setup
Torque
Type
Signal
Name
Connector Pin
Number
Setting Meaning
Output /S-RDY Must be allocated
ON (closed)
The SERVOPACK is ready to accept the Servo ON
command.
OFF (open)
The SERVOPACK is not ready to accept the Servo
ON command.
To Next Page
