3.8 Selecting and Connecting a Regenerative Resistor Unit
The SERVOPACKs and converters do not contain a regenerative resistor. Select and connect a regenerative
resistor unit and set the regenerative resistor capacity in Pn600 as described in this section.
For detailed specifications of the regenerative resistor units, refer to Large-Capacity
Σ -V Series Catalog (No.:
KAEP S800000 86).
3.8.1 Selecting a Regenerative Resistor Unit
(1) Using a Regenerative Resistor Unit Specified by Yaskawa
The regenerative resistor units specified by Yaskawa are listed in the following table. You must acquire the
regenerative resistor units separately.
If you use a regenerative resistor unit specified by Yaskawa, use it only in one of the combinations that are
given in the following table.
(2) Using a Non-Specified Regenerative Resistor Unit
If you use non-specified regenerative resistor units, contact your Yaskawa representative or the sales depart-
ment for more details.
WARNING
• Be sure to connect the regenerative resistor unit correctly. Do not short-circuit between B1 and B2.
Doing so may result in fire or damage to the regenerative resistor unit, SERVOPACK, or converter or other devices.
Main Circuit
Power Supply
Voltage
SERVO-
PACK
Model
SGDV-
Converter
Model
SGDV-COA
Model of Applicable
Regenerative
Resistor Unit
Resis-
tance
(Ω)
Specifications
Three-phase
200 V
121H 2BAA JUSP-RA08-E 2.4
Four 0.6-Ω (600-W) resistors con-
nected in series
161H
3GAA
JUSP-RA09-E 1.8
Two sets of four 0.9-Ω (600-W)
resistors connected in series are
connected in parallel.
201H JUSP-RA11-E 1.6
Eight 0.2-Ω (600-W) resistors con-
nected in series
Three-phase
400 V
750J 3ZDA JUSP-RA13-E 6.7
Three sets of two 10-Ω (600-W)
resistors connected in series are
connected in parallel.
101J
5EDA
JUSP-RA14-E 5
Four sets of two 10-Ω (600-W)
resistors connected in series are
connected in parallel.
131J JUSP-RA16-E 3.8
Four sets of three 5-Ω (600-W)
resistors connected in series are
connected in parallel.
If you use a non-specified regenerative resistor unit, we recommend that you use a
regenerative resistor unit with a thermal switch for safety.

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
