6 Utility Functions (Fn)
6-28
6.17 Display of SERVOPACK and Servomotor ID (Fn01E)
This function displays ID information for SERVOPACK, servomotor, encoder, and option module connected
to the SERVOPACK. The ID information of some option modules (SGDV-OFA01A) is not stored in the SER-
VOPACK. "Not available" will be displayed for these option modules.
To use this function, the digital operator (JUSP-OP05A-1-E) or SigmaWin+ is needed.
Refer to
Σ -V Series User's Manual, Operation of Digital Operator (No.: SIEP S800000 55) for the operating
procedure of the digital operator.
The following items can be displayed.
∗ If the option module is not connected, "Not connect" will be displayed after the module name.
(1) Preparation
There are no tasks that must be performed before the execution.
ID Items to be Displayed
SERVOPACK ID
• SERVOPACK model
• SERVOPACK serial number
• SERVOPACK manufacturing date
• SERVOPACK input voltage (V)
• Maximum applicable motor capacity (W)
• Maximum applicable motor rated current (Arms)
Servomotor ID
• Servomotor model
• Servomotor order number
• Servomotor manufacturing date
• Servomotor input voltage (V)
• Servomotor capacity (W)
• Servomotor rated current (Arms)
Encoder ID
• Encoder model
• Encoder serial number
• Encoder manufacturing date
• Encoder type/resolution
Command Option
Module*
• Command option module model
• Command option module serial number
• Command option module manufacturing date
• Command option module ID number
Safety Option Module
ID
*
• Safety Option Module model
• Safety Option Module serial number
• Safety Option Module manufacturing date
• Safety Option Module ID number
Feedback Option
Module ID
*
• Feedback Option Module model
• Feedback Option Module serial number (Reserved area)
• Feedback Option Module manufacturing date
• Feedback Option Module ID
