2.2 Operation of Digital Operator
2-3
2
Panel Display and Operation of Digital Operator
2.2 Operation of Digital Operator
Operation examples of utility functions (Fn), parameters (Pn) and monitor displays (Un)
when using a digital operator are described in this chapter.
Operations can be also performed with SigmaWin+.
For more information on the usage of the digital operator, refer to
Σ -V Series USER’S MANUAL Operation of
Digital Operator (No.: SIEP S800000 55).

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
