4.1 Setting Switches S2 and S3 for Option Module Functions
4-3
4
Operation
4.1 Setting Switches S2 and S3 for Option Module Functions
The S3 DIP switch is used to make the settings for the option module functions.
For details on S2 and S3 switches, refer to the manual of the connected command option module.
ᴾ
S3
POWER LED
S2
Seven-segment
LED display
ON
OFF
1234
0
F1
E2
D3
8
4C
B5
A6
97
M-II

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
