1.10 Combinations of Servomotors, SERVOPACKs, and Converters
1-15
1
Outline
1.10 Combinations of Servomotors, SERVOPACKs, and
Converters
The following table lists the combinations of servomotors, SERVOPACKs, and converters.
Main Circuit Power
Supply Voltage
Servomotor SERVOPACK Converter
Motor speed Model: SGMVV- Capacity Model: SGDV-
Model: SGDV-
COA
Three-phase
200 VAC
1500 min
-1
2BAB 22 kW 121H 2BAA
3ZAB 30 kW 161H
3GAA
3GAB 37 kW 201H
800 min
-1
2BAD 22 kW 121H 2BAA
3ZAD 30 kW 161H
3GAA
3GAD 37 kW 201H
Three-phase
400 VAC
1500 min
-1
2BDB 22 kW
750J 3ZDA
3ZDB 30 kW
3GDB 37 kW 101J
5EDA4EDB 45 kW
131J
5EDB 55 kW
800 min
-1
2BDD 22 kW
750J 3ZDA
3ZDD 30 kW
3GDD 37 kW 101J
5EDA
4EDD 45 kW 131J
