YASKAWA SGDV series User Manual

1-1
1
Outline
1
Outline
1.1 Σ-V Large-Capacity SERVOPACKs and Converters . . . . . . . . . . . . . . . . .1-2
1.2 SERVOPACKs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 SERVOPACK Part Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.4 Converter Part Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
1.5 Ratings and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
1.5.1 Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.5.2 Basic Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
1.6 SERVOPACK and Converter Internal Block Diagrams . . . . . . . . . . . . . . 1-10
1.6.1 Three-phase 200 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
1.6.2 Three-phase 400 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
1.7 Examples of Servo System Configurations . . . . . . . . . . . . . . . . . . . . . . .1-12
1.8 SERVOPACK Model Designation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.9 Converter Model Designation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
1.10 Combinations of Servomotors, SERVOPACKs, and Converters . . . . . . 1-15
1.11 Inspection and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-16

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
