Pn170
2 Tuning-less Function Related Switch 0000 to 2411 − 1401 − ––
Pn190 2 Reserved (Do not change.) – – 0010 – – –
Pn200 2 Reserved (Do not change.) – – 0100 – – –
Pn205 2 Multiturn Limit Setting 0 to 65535 1 rev 65535 After restart Setup 4.5.6
Pn207
2 Position Control Function Switch 0000 to 2210 − 0010 After restart Setup −
Pn20A 4 Number of External Scale Pitch 4 to 1048576
1
pitch/rev
32768 After restart Setup 8.3
Pn20E 4 Electronic Gear Ratio (Numerator)
1 to
1073741824
1 4 After restart Setup 4.2.4
Pn210 4 Electronic Gear Ratio (Denominator)
1 to
1073741824
1 1 After restart Setup 4.2.4
Pn212 4 Encoder Output Pulses
16 to
1073741824
1 P/rev 2048 After restart Setup 4.2.6
Pn216 2 Reserved (Do not change.) – – 0 – – –
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classi-
fication
Reference
Section
Tuning-less Function Selection
When
Enabled
Classification
Reference
Section
0 Disables tuning-less function.
After restart Setup
5.2
1 Enables tuning-less function.
Control Method during Speed Control
When
Enabled
Classification
Reference
Section
0 Uses as speed control.
After restart Setup
5.2
1
Uses as speed control and uses the host controller for
position control.
Rigidity Level
When
Enabled
Classification
Reference
Section
0 to 4 Sets rigidity level. Immediately Setup
5.2
Load Level
When
Enabled
Classification
Reference
Section
0 to 2 Sets load level. Immediately Setup
5.2
4th 3rd 2nd 1st
digit digit digit digit
n.

Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
/COIN Output Timing
Reference
Section
0 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522).
4.6.6
1 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522), and the reference after position reference
filtering is 0.
2 Outputs when the position error absolute value is the same or less than the
positioning completed width (Pn522), and the position reference input is 0.
