YASKAWA SGDV series User Manual

3.1 Main Circuit Wiring
3-13
3
Wiring and Connection
 Tools for Crimp Terminals
Model
Tools by J.S.T. Mfg Co., Ltd.
Body Head Dies
R5.5-6 YHT-2210 – –
R8-8
YHT-8S – –
YPT-150-1 – TD-221, TD-211
R14-8
Body only: YPT-150-1
or
Body: YF-1; Head: YET-150-1
TD-222, TD-211
R22-10 TD-223, TD-212
R38-8
R38-10
TD-224, TD-212
R60-8 TD-225, TD-213
70-8
70-10
TD-226, TD-213
80-8
80-10
CB80-S8
TD-227, TD-214
100-8
R100-10
TD-228, TD-214
150-8
CB150-S10
TD-229, TD-215

YASKAWA SGDV series Specifications

General

Series	SGDV
Communication	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Control Modes	Position, Speed, Torque
Protection Features	Overcurrent, Overvoltage, Undervoltage, Encoder error
Ambient Temperature	0°C to 55°C
Cooling Method	Natural cooling or forced air cooling
Voltage	200V, 400V
Weight	Varies depending on model (e.g., 0.6 kg to 10 kg)
