3 Wiring and Connection
3.2.2 Interconnecting Terminals
3-22
(1) SGDV-COA2BAA, -COA3ZDA Converters
Attach the busbars as shown in the following figure.
Note: The shapes of the ends of the busbars are different for the SERVOPACK and converter connections and for the P ter-
minal and N terminal connections.
(2) SGDV-COA3GAA, -COA5EDA Converters
The busbars can be connected in any direction.
Converter’s P terminal
Converter’s N terminal
SERVOPACK’s P terminal
SERVOPACK’s N terminal
To Next Page
