6-4
IM AQ7280-01EN
File Menu
Press FILE to display the File menu.
The file menu on the AQ7280 varies depending on the feature in use.
• When the OTDR, OTDR Smart Mapper, Fault Locator, or power meter feature of the top
screen or top menu is in use
Set the action (Save, Load).
Set the file type.
Set the extension for saving or loading.
For details, see the explanation later in this section.
Set the save destination drive
(Int. Memory, USB Memory 1, USB Memory 2, SD Card).
Set the file name.
Set the file name format. You can set this when Action is set to Save.
Start saving or loading.
This soft key is Save or Load depending on the Action setting.
• When the multi-core fiber measurement or schedule measurement feature is in use
Set the action (Save, Load).
Save can be used for multi-core fiber measurement.
The file type is fixed. The extension for saving or
loading is displayed. For details, see the
explanation later in this section.
Set the save destination drive
(Int. Memory, USB Memory 1, USB Memory 2, SD Card).
Start saving or loading.
This soft key is Save or Load depending on the Action setting.
6.3 Saving and Loading Data
To Next Page
