6 Point Markers
Press the 6 Point Markers soft key to display the following screen.
Sets marker .
Marker is set at the cursor
position.
1
1
Sets marker .
Marker is set at the cursor
position.
2
2
Cursor link
See 2 Point markers.
Set marker Y2.
Marker Y2 is set at the cursor
position.
Sets marker .
Marker is set at the cursor
position.
3
3
Set marker Y1.
Marker Y1 is set at
the cursor position.
3
Marker
Marker Y2
1
Marker
Marker information
Set marker Y3.
Marker Y3 is set at
the cursor position.
Marker Y3
Marker Y1
Note
• Set the markers in the order shown above, starting with the measurement start point (the distance
reference).
• The measured loss value differs depending on the specified approximation method.
• Set the correct position for
2
. The splice loss changes greatly depending on the position of
2
.
