6-19
IM AQ7280-01EN
File Operation and Printing
1
2
3
4
5
6
7
8
Index
6.8
Creating Reports of Waveform Data as PDF Data
CAUTION
Do not remove a USB memory device or turn off the power when the USB memory access
indicator is blinking or when data is being saved or loaded from internal memory. Doing so
may damage the storage medium (USB memory or internal memory) or corrupt its data.
French
ATTENTION
N'enlevez pas un dispositif de mémoire USB et ne coupez pas l'alimentation électrique
lorsque l'indicateur d'accès à la mémoire USB clignote ou lorsque les données sont en train
d'être enregistrées ou chargées à partir d'une mémoire interne. Vous risqueriez
d'endommager le support de stockage (mémoire USB ou mémoire interne) ou les données
qu'il contient.
Procedure
Exporting a Report of Waveform Data to PDF
Press FILE to display the following screen.
Set the action
(Report, File Report).
Select the target drive
(
Int. Memory, USB Memory 1,
USB Memory 2, SD Card).
Set the report format.
You can select the items
to include in the report.
Using the rotary knob and ENTER, select a file
to export to PDF.
A check mark appears next to the selected file.
To clear the selection, press ENTER again.
Pressing the Save soft key displays a screen
for selecting the PDF output folder.
Select a folder on this screen, and press the
Save soft key to export to PDF.
PDF files are exported for all the selected files.
