Setting the Report Format (Report)
Press the Setup soft key to display the following screen.
Select the items to include in the report.
For details on the items, see “Explanation”
in this section.
When Action is set to Report
Fiber end face image
(OFF, Manual, Auto)
For details on the items, see
“Explanation” in this section.
Set the file name.
See “File Name Setup Screen” in section 6.3.
Select the items to include in the report.
For details on the items, see “Explanation”
in this section.
Setting the Report Format (File Report)
Press the Setup soft key to display the following screen.
Report format
Set the number of waveforms and the event
items to show in the report.
When Action is set to File Report
Format display for two waveforms
The items are the same as for “Report.”
6.8 Creating Reports of Waveform Data as PDF Data
To Next Page
