File Operation and Printing
1
2
3
4
5
6
7
8
Index
• Multi-Core Fiber Measurement
Display Description
— Waveform data from measuring multi-core fiber (including the measurement conditions)
is saved in an SOR file format that conforms to Telcordia SR-4731. When Action is set
to Save or Load, file type cannot be changed. Moreover, SOR files do not appear in the
file list.
— Screen image data of the fiber inspection probe is saved to a file in BMP format. When
Action is set to Save or Load, file type cannot be changed. Moreover, BMP files do not
appear in the file list.
*.MPZ SOR files, MPJ files, and BMP files are compressed and saved to MPZ files. They can
be used as storage files. For the decompression procedure, see “Note” under “Saving
the Project” in section 2.8.
*.TXT Multi-core fiber measurement conditions, waveform data summary information, and
optical power measurements are saved to a tab separated file (firmware version 1.07
and later).
• Schedule Measurement
Display Description
— Waveform data measured according to the specified schedule (including the
measurement conditions) is saved in an SOR file format that conforms to Telcordia SR-
4731. When Action is set to Save or Load, file type cannot be changed. Moreover, SOR
files do not appear in the file list.
*.CSV Schedule information and measured optical power values (including measurement
conditions) are saved to a file in CSV format.
• OTDR Smart Mapper
Display Description
*.SOR Waveform data measured from an optical pulse (including the measurement conditions)
is saved in an SOR file format that conforms to Telcordia SR-4731.
*.BMP Screen image data is saved to a file in BMP format.
*.JPG Screen image data is saved to a file in JPG format.
*.SOR|*.BMP Both SOR and BMP files are saved.
*.SOR|*.JPG Both SOR and JPG files are saved.
.CSV (waveform) Waveform data measured from an optical pulse is saved to a file in CSV format.
.CSV (event) Event data is saved to a file in CSV format.
*.SMP Adapt Trace data measured from an optical pulse (including the measurement
conditions) is saved to a file in SMP format.
The screen image immediately before entering the file operation screen is saved.
• Power Meter
Display Description
*.CSV Measured optical power values (including measurement conditions) are saved to a file
in CSV format.
• Fiber Inspection Probe
Display Description
*.BMP Screen image data is saved to a file in BMP format.
*.JPG Screen image data is saved to a file in JPG format.
Loading
The following types of files can be loaded.
• Top Screen
Display Description
*.CFG System settings are loaded.
• OTDR feature
Display Description
*.SOR Optical pulse waveform (including measurement conditions) in SOR format that
conforms to Telcordia SR-4731 is loaded.
*.SET Measurement conditions are loaded.
6.3 Saving and Loading Data
