Zebra DS8108 User Manual

Standard Parameter Defaults A - 3
RS-232 Host Parameters
RS-232 Host Types N/A N/A Standard 6-6
Baud Rate N/A N/A 9600 6-8
Parity N/A N/A None 6-9
Stop Bits N/A N/A 1 Stop Bit 6-10
Data Bits N/A N/A 8-bit 6-10
Check Receive Errors N/A N/A Enable 6-11
Hardware Handshaking N/A N/A None 6-11
Software Handshaking N/A N/A None 6-13
Host Serial Response Timeout N/A N/A 2 Sec 6-15
RTS Line State N/A N/A Low RTS 6-16
Beep on <BEL> N/A N/A Disable 6-16
Intercharacter Delay N/A N/A 0 msec 6-17
Nixdorf Beep/LED Options N/A N/A Normal Operation 6-18
Bar Codes with Unknown Characters N/A N/A Send Bar Code With
Unknown Characters
6-18
IBM 468X/469X Host Parameters
Port Address N/A N/A None 7-4
Convert Unknown to Code 39 N/A N/A Disable 7-5
RS-485 Beep Directive N/A N/A Honor 7-5
RS-485 Bar Code Configuration
Directive
N/A N/A Ignore 7-6
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type N/A N/A IBM AT Notebook 8-4
Bar Codes with Unknown Characters N/A N/A Send Bar Codes with
Unknown Characters
8-4
Keystroke Delay N/A N/A No Delay 8-5
Intra-keystroke Delay N/A N/A Disable 8-5
Alternate Numeric Keypad Emulation N/A N/A Enable 8-6
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
