180 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
No. Text S A
W
F Reaction/Comment
116 The Profibus module is in-
stalled on a wrong slot! The
Profibus interface is therefore
not functional. Please install
the Profibus module on the slot
X20/X21.
x x see message text
117 The configuration backup was
saved.
118 The configuration backup was
loaded and the system re-
started.
119 The system configuration could
not be loaded. For that reason,
the system does not currently
contain a configuration. Please
load in the menu: Config-
ure/System/
Save configuration the backup
configuration. Or load a con-
figuration with the use of SMT.
x x see message text
120 All passwords are reset to the
system defaults. Please save the
configuration, power off the
system and remove the jumper.
Then repower the system.
see message text
121 The maintenance switch is ON. x for information
122 The system disk has been rei-
nitialized! This system contains
no configuration now! Please
use SMT to reinstall your con-
figuration.
x see message text
QAL3
126 The QAL3 historien buffer is
full. Please read-out QAL3 data.
x see message text
127 The calibration drift exceed the
QAL3 limits.
x
System bus
201 The system bus module se-
lected could not be found.
x x Check plug connections and terminal resistances on the
system bus. Check whether the serial number of the
system bus was entered correctly.
MENU → Diagnosis/Information → System overview
203 The system bus module does
not exist.
x x Check plug connections and terminal resistances on the
system bus.
208 The system bus could not
transfer any data to the data-
base.
x x The software version of the system bus module is not
compatible with that of the system controller; carry out
system update of the system controller.
209 The system bus connection
to this module is interrupted.
x x Check system bus connection to the system bus module
displayed. Check power supply of the displayed system
bus module.
210 The configuration of the sys-
tem bus module has changed.
x x for information; the configuration data are updated
automatically
211 The system bus module no
longer has an internal memory.
x x Check configuration of the system bus module:
MENU → Diagnosis/Information → System overview
