POWER Indicator
This green indicator illuminates when you turn on the film recorder.
MENU Button
Press to access the PCR II Plus user menu.
SELECT
Activates the function displayed in the message window.
PREVIOUS
Scrolls backward through the displayed menu or submenu.
NEXT
Scrolls forward through the displayed menu.
RESET
Resets all the functions of the PCR II PLUS. Use this if a fault condition causes the
film recorder to cease operation.
GPIB/SCSI Switch
Enables you to select either GPIB or SCSI operation, depending on the type of
host computer you are using to output images.
MESSAGE WINDOW
16-digit, 2-line LCD (liquid crystal display). Status and error messages appear in
this window.
