SCSI Interface Ports
These accept SCSI computer interface cables for transmitting data and commands
to the PCR II Plus. Use these ports to connect the film recorder to a Macintosh or
other device that uses the SCSI protocol.
GPIB Interface Port
Accepts the IEEE-488 computer interface cable for transmitting data and com-
mands to the PCR II Plus. Use this port if your host computer supplies GPIB out-
put.
Power Switch
Turns the film recorder on and off.
Socket
Input connector for the power cord.
Fuse
Protects the film recorder's electrical systems by breaking the circuit when the cur-
rent exceeds the rated value. The fuse value is stamped on the serial number tag.
Product Description • 1-9
