AGFA PCR II Plus - Page 35

Figure 2 8 Multiple device setup with the PCR II Plus in the middle of the chain
-Macintosh host computer, terminated Internally —SCSI peripheral device A
—PCR II Plus with internal termination off
—SCSI peripheral device B —SCSI interface in —SCSI interface out
—Terminator for the end of the SCSI chain Not required if this device can be
internally terminated
Figure 2 9 Multiple device setup with the PCR II Plus at the end of the chain
-Macintosh host computer, terminated Internally
—SCSI peripheral device A —SCSI peripheral device B
—PCR II Plus with internal termination on
—SCSI interface in —SCSI interface out
Installation • 2-9
