1140 Typical Valve Configurations
4 of 10
Jun 2001
Valves
Agilent 6890 Gas Chromatograph Service Manual
Column
Carrier
Detector
OFF ON
Backflush to Detector, Option 704 or 734
Precolumn
1st Carrier
2nd Carrier
Detector
Column
Backflush a Precolumn to Vent, Option 705 or 735
OFF
ON
Vent
