Agilent Technologies 6890 Series Service Manual

1210 External Connectors, 6890A and 6890 Plus
Overview
2 of 14
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
The table details the additional external connectors used on the 6890 Plus GC.
Note The external RS-232 connector for the sampler is not used on this model.
Figure 1210-2 6890 Plus GC external connections
Number Description ID
Connector
5
Not used for 6890 Plus GC’s
11
Sampler–G2613A Automatic Liquid
Sampler, front injector*
12
JP2
P2
P4
13
Sampler–G2614ATray
P3
11
12
13
5
Back of 6890 Plus GC with G2612A ALS
PCB Installed
Interface
Sampler–G2613A Automatic Liquid
Sampler, back injector*
* Default configuration
