Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
External Connectors, 6890A and 6890 Plus 1210
Signal 1/Signal 2 analog out
Signal 1/Signal 2 analog out
J1, J2
Analog out
Pin Function
1 1 mV COM
2 1 V & 10 V COM
3 1 mV
4 1 V
5 Chassis GND
5
3
1
2
4
6
5
3
1
2
4
6
6
10V
