3 of 10
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
Power Supply 1230
Setting the instrument power configuration
Oven shroud
There are two different oven shrouds depending on the power option used.
The oven shroud contains the oven heater and sensor as part of the assembly.
If you need to replace the heater or sensor, you should replace the entire
shroud assembly. See Replacing the oven shroud assembly in the Oven and
Temperature Control chapter for more details.
Table 1230-3 Part Numbers for Oven Shrouds and Configuration Plugs
Regular oven shrouds
Voltage Shroud part no. Configuration plug part no.
120 V G1530-61610 G1530-60690
230 V G1530-61670 G1530-60720
Fast ramping oven shrouds
Voltage Shroud part no. Configuration plug part no.
200 V G1530-61620 G1530-60700
208 V G1530-61630 G1530-60710
220 V G1530-61630 G1530-60710
230 V G1530-61650 G1530-60720
240 V G1530-61640 G1530-60730
