1230 Power Supply
Replaceable AC board fuses
4 of 10
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
Replaceable AC board fuses
There are four fuses on the AC power board.
• The two glass fuses are identical for all power options.
• The two ceramic fuses come in two types: one for the 120 V power option
and another type for all other power options.
When replacing both the glass and ceramic fuse types, always replace them
in pairs.
Table 1230-4 Replaceable Fuses on the AC Power Board
I.D. Description System Power rating Part no.
F1 Ceramic/Type F Oven heater 120 V systems: 20A/250 V
200 V–240 V systems: 15A/250 V
2110-0098
2110-0054
F2 Ceramic/Type F Oven heater 120 V systems: 20A/250 V
200 V–240V systems: 15A/250 V
2110-0098
2110-0054
F3 Glass/Type F All other systems
except heater
8A/250 V 2110-0036
F4 Glass/Type F All other systems
except heater
8A/250 V 2110-0036
