Agilent Technologies 6890 Series Service Manual

7 of 10
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
Power Supply 1230
AC power board circuitry
AC power board circuitry
Main power switch
LM1/XFRMR OA
(Actuated by
push-rod from
front of unit)
BA, 250 VAC
Fast-acting, 3AG
p/n 2110-0036
Glass body
LN2/Neutral
Line
voltage
Oven circuit
Fuse rating p/n
120 V:
200-240V:
20A, 250 VAC
15A, 250 VAC
2110-0098
2110-0054
All fuses: 3AB, IEC 127 TYPE F,
(fast-acting), Ceramic Body
Line 1
(Black, Brown)
AC LINE INPUT
Line 2
Neutral
(White, Blue)
Primary circuits
Secondary circuits
Main board interface
PS
Oven fly
Oven triac
+24V
Oven triac
Oven fly
Secondary circuits
Primary circuits
6
5
4
3
1
2
