Agilent Technologies 6890 Series Service Manual

1230 Power Supply
AC power board circuitry
8 of 10
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
AC power board circuitry (continued)
P8
Fan_Blue
XFRMR_100B XFRMR_120B FAN_ORANGE XFRMR_110B XFRMR_OB TRIAC_MT2 FAN_YELLOW XFRMR_120A OVN/FAN_BRN MT1/FAN WHT XFRMR_100A LN2/Neutral LN2/Neutral LN!/XFRMR_OA
1 2 3 4 5 6 7 8 9 10 11 12 13 15
LN!/XFRMR_OA
XFRMR_100A
XFRMR_120A
XFRMR_08
XFRMR_100B
XFRMR_110B
XFRMR_120B
BLK OV
BLK/ORN100V
BLK/YEL 120V
BLK/GRNOV
BLK/BLU100V
BLK/WHT
BLK/RED
110V
120V
14
1
2
3
FAN_YELLOW
FAN_BLUE
OVN/FAN_BRN
MT1/FAN_WHT
FAN_ORANGE
YELLOW
BLUE
BROWN
WHITE
ORANGE
LINE VOLTAGE
CONFIGURATION CONNECTOR
(shown configured for
120 VAC operation)
VIOLET
GRAY
WHITE
ORANGE
YELLOW
BLUE
YELLOW
POWER TRANSFORMER ASSEMBLY
Secondaries
Violet- Orange: Heater Power
Yellow- Yellow: dc Supplies
42 V(rms) - nos.
Commonly-grounded
on Main Board
42 V(rms) - nos.
24 V(rms) - nos.
24 V(rms) - nos.
OVEN FAN MOTOR ASSEMBLY
GREEN/YELLOW
OVEN
HEATER
TRIAC
4
5
6
P8
