Agilent 6890 Gas Chromatograph Service Manual
Purged/Packed Inlet 220
Replacement procedures
Figure 220-7 Removing the thermal block
10. Reinstallation is the reverse of removal.
Inlet weldment
Thermal block
Bottom nut
