Agilent 7100 Capillary Electrophoresis System User Manual 213
Maintenance 8
Cleaning the Electrodes, Pre-punchers and Insulation Plate
10 Tighten the slotted screws in the front of the liquid handling module.
Figure 70 Liquid handling module
11 Reconnect the line power, drainage, external pressure supply, the
connectors for an external cooling bath (if applicable), and switch on the
instrument.
12 Reestablish the connection to the instrument from the Lab Advisor
software. Select Start monitoring.
3. Front screws of the
liquid handling module
2. Put in bottles
1. Push liquid handling
module in
No high voltage can be applied, if the front cover is removed. Touching the electrodes inside
the instrument is safe. However, under the following circumstances (usage of the
alignment center), slow lifter movements with a low force are possible with the following
alignment procedure. When you start any lifter movement your hands should be outside the
instrument.
