71
4 Maintenance and troubleshooting
Changing the Bravo head
Bravo Platform User Guide
4 Open Diagnostics, and in the Jog/Teach tab, make sure that a value is displayed
for each axis.
This confirms communication between the Bravo Platform and VWorks
software.
5 If you opened an existing device file in step 1, go to the Configuration tab in
Diagnostics and verify that the location configuration graphic matches what you
actually have on the Bravo deck.
Related information
For information about... See...
Tips Off task in Bravo Diagnostics “Performing a task using Bravo Diagnostics”
on page 100
Initializing the Bravo Platform “Initializing the device” on page 31
Homing the Bravo head “Homing the liquid-handling head” on page 90
Available Bravo heads “Liquid-handling heads” on page 11
Changing the profile “Creating and managing profiles” on page 26
