4 System Related Operation
Utility Menu Summary
112 U3606A User’s and Service Guide
IOb
GPib U-CdC U-tMC
• Select “GPib”, “U-tMC”, or “U-CdC” as the desired remote
interface connection.
• “USB-tMC” simulates the USB interface according to
USB-TMC standard.
• “USB-CdC” is used to simulate the communication port.
• See “Connecting to a remote interface” on page 118 and
“Remote Operation” on page 130 for more information.
NN
• Set the GPIB address from 1 to 30.
• See “Configuring and connecting the GPIB interface” on
page 131 for more information.
SELF.t no YES
• If “YES” is selected, the instrument exits the utility menu
and immediately executes the self-test.
• After the self-test completes, the instrument returns to
normal operation.
• See “Performing a self-test” on page 120 for more
information.
db.rEF NNNN Ω
• Set dB reference impedance value from 1 Ω to 9999 Ω.
• See “Selecting a dBm reference resistance value” on
page 121 for more information.
SCAn
CV CC
• Press Voltage to select scan setup for CV.
• Press Current to select scan setup for CC.
S1/S2 S1/S2
Press Shift > Range to toggle between range S1 (30 V/1 A) or
S2 (8 V/3 A)
NN.NNN V N.NNNN A NNN-NN s
• The increment of each step will be the amplitude end
position (NN.NNN V/N.NNNN A) divided by the number of
steps (NNN S).
• Set the scan dwelling time (NN s) from 1 s to 99 s.
• See “Configuring the scan signal parameters” on page 124
for more information.
Table 4 - 2 Utility menu item descriptions
Item Available settings Description
