8 Characteristics and Specifications
DC Power Supply Specifications
252 U3606A User’s and Service Guide
Supplementary specifications
Maximum output
programming range:
Range S1
• CV/CC: 0 V to 31.500 V/0 A to 1.05 A
• OV/OC: 31.500 V/1.05 A
• OVP/OCP: 33.000 V/1.1 A
Range S2
• CV/CC: 0 V to 8.4 V/0 A to 3.15 A
• OV/OC: 8.4 V/3.15 A
• OVP/OCP: 8.8 V/3.3 A
Temperature coefficient:
± (% of output + offset)
maximum change in
output/readback per °C for
0 ºC to 18 ºC/28ºC to 55 ºC
• Voltage: 0.005% + 0.5 mV
• Current: 0.02% +1 mA
Remote sensing capability: Output can maintain specifications for
• Range S1 (30 V/1 A): Up to a 0.75-volt drop per load lead.
• Range S2 (8 V/3 A): Up to a 0.5-volt drop per load lead.
Voltage programming speed:
(excludes command
processing time)
Full load
• Up: 300 ms
• Down: 400 ms
No load
• Up: 300 ms
• Down: 400 ms
