Agilent Technologies U3606A User Manual

5 Verification and Performance Tests
Input Connections
146 U3606A User’s and Service Guide
Figure 5-10 Test setup for CC line and load regulation verification
Figure 5-11 Test setup for CC noise effect verification
LOAD
Digital multimeter
Electronic
load
Current monitoring resistor
–
+
–V
+V
V
out
V 1
V
2
R
1
R
1
R 2
R 2
TCPA300
TCP305
Fix resistive load
Differential amplifier
RMS voltmeter
50 Ω
termination
BNC
BNC
BNC
AC/DC converter
