Agilent Technologies U3606A User Manual

Characteristics and Specifications 8
Digital Multimeter Specifications
U3606A User’s and Service Guide 239
DC specifications
Table 8 - 1 DC accuracy specifications ± (% of reading + % of range)
Function Range
[1]
Test current or
burden voltage
24 Hours
[2]
23 ºC ± 1 ºC
90 Days
23 ºC ± 5 ºC
1 Year
23 ºC ± 5 ºC
Temperature
coefficient
0 ºC to 18 ºC
28 ºC to 55 ºC
DC voltage
100.000 mV - 0.012 + 0.008 0.015 + 0.008 0.025 + 0.008 0.0015 + 0.0005
1.00000 V - 0.012 + 0.005 0.015 + 0.005 0.025 + 0.005 0.0010 + 0.0005
10.0000 V - 0.012 + 0.005 0.015 + 0.005 0.025 + 0.005 0.0020 + 0.0005
100.000 V - 0.012 + 0.005 0.015 + 0.005 0.025 + 0.005 0.0015 + 0.0005
1000.00 V - 0.012 + 0.005 0.015 + 0.005 0.025 + 0.005 0.0015 + 0.0005
DC current
[3]
10.0000 mA < 0.2 V 0.05 + 0.015 0.05 + 0.015 0.05 + 0.015 0.0060 + 0.0005
100.000 mA < 0.2 V 0.05 + 0.005 0.05 + 0.005 0.05 + 0.005 0.0060 + 0.0005
1.00000 A < 0.3 V 0.05 + 0.007 0.05 + 0.007 0.15 + 0.007 0.0100 + 0.0005
3.0000 A < 0.7 V 0.05 + 0.007 0.05 + 0.007 0.15 + 0.007 0.0150 + 0.0010
Resistance
[4]
100.000 Ω 0.83 mA 0.04 + 0.008 0.04 + 0.008 0.05 + 0.008 0.0050 + 0.0005
1000.00 Ω 0.83 mA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005
10.0000 kΩ 100 µA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005
100.000 kΩ 10 µA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005
1.00000 MΩ 900 nA 0.05 + 0.005 0.05 + 0.005 0.06 + 0.005 0.0050 + 0.0005
10.0000 MΩ 205 nA 0.20 + 0.005 0.20 + 0.005 0.25 + 0.005 0.0150 + 0.0005
100.000 MΩ
205 nA ||
10 MΩ
1.60 + 0.005 1.60 + 0.005 2.00 + 0.005 0.1500 + 0.0005
Low-resistance
[5]
100 mΩ 1.0000 A - - 0.25 + 0.05 -
1000 mΩ 0.1000 A - - 0.25 + 0.03 -
10 Ω 0.1000 A - - 0.25 + 0.03 -
Continuity 1.0000 kΩ 0.83 mA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050+0.0005
Diode
[6]
1.0000 V 0.83 mA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005

Agilent Technologies U3606A Specifications

General

Brand	Agilent Technologies
Model	U3606A
Category	Multimeter
Language	English
