Calibration Procedures 6
Adjustments procedures
U3606A User’s and Service Guide 201
6 Enter the actual applied input (see “Entering adjustment values” on
page 184).
7 Press to start the adjustment. The display “CALib” in the lower
secondary display starts flashing to indicate that the calibration is in
progress.
• Successful completion of the adjustment is indicated by a short beep
and the primary display briefly showing “PASS”.
• An adjustment failure is indicated by a long beep, the primary
display showing “FAiL” and a calibration error number appearing in
the upper secondary display. Correct the problem and repeat this
procedure.
8 Repeat step 3 through step 7 for each gain adjustment point shown in
Table 6- 8.
9 Verify the AC current gain adjustments using the “AC current
verification test” on page 154.
Capacitance gain adjustment procedure
Review the “Test Considerations” on page 140 and “Gain adjustment
considerations” on page 191 sections before beginning this procedure.
1 Press to enter the capacitance gain calibration.
2 The primary display will show the uncalibrated value and the upper
secondary display will show the reference value of the adjustment item.
3 Configure each adjustment item shown in Table 6- 9.
Table 6 - 8 AC current gain adjustment
Adjustment item Input current Input frequency
1.0000 mA, 1 kHz 1 mA 1 kHz
10.0000 mA, 1 kHz 10 mA 1 kHz
100.000 mA, 1 kHz 100 mA 1 kHz
1000.00 mA, 1 kHz 1000 mA 1 kHz
