System Related Operation 4
Storing and Recalling Instrument States
U3606A User’s and Service Guide 129
Recalling a stored state
To recall an instrument state:
1 Press Shift > Recall. The Recall annunciator will begin flashing.
2 Press or until the state number (01 to 16) you want to recall
from is shown on the primary display.
3 Press Shift > Save to recall the selected state. The upper secondary
display briefly shows “donE” when the state is successfully recalled.
4 The instrument will then return to normal operation.
Select state 00 to recall the instrument last power-down state.
