Agilent Technologies U3606A - Table 5-6 AC Current Gain Verification Test; Table 5-7 Resistance Gain Verification Test

Verification and Performance Tests 5
Performance Verification Tests
U3606A User’s and Service Guide 155
Resistance gain verification test
1 Connect the calibrator to the front panel (red) and LO (black) input
terminals (see Figure 5- 2 on page 142).
2 Press to select the resistance function.
3 Select each range in the order shown below. Provide the indicated input
resistance. Compare the measurement results to the appropriate test
limits shown in Table 5- 7. (Be certain to allow for appropriate source
settling when using the Fluke 5520A.)
Table 5 - 6 AC current gain verification test
Input current Input frequency Range
Error from
nominal 1 year
1 mA 1 kHz 10 mA ±0.015 mA
10 mA 1 kHz 10 mA ±0.06 mA
10 mA 1 kHz 100 mA ±0.15 mA
100 mA 1 kHz 100 mA ±0.6 mA
0.1 A 1 kHz 1 A ±0.0015 A
1 A 1 kHz 1 A ±0.006 A
1 A 1 kHz 3 A ±0.008 A
3 A 1 kHz 3 A ±0.018 A
Table 5 - 7 Resistance gain verification test
Input resistance Range Error from nominal 1 year
100 Ω 100 Ω ±0.058 Ω
[1]
1 kΩ 1 kΩ ±0.00055 kΩ
[1]
10 kΩ 10 kΩ ±0.0055 kΩ
[1]
100 kΩ 100 kΩ ±0.055 kΩ
1 MΩ 1 MΩ ±0.00065 MΩ
