Agilent Technologies U3606A - Table 5-18 Square-Wave Duty Cycle Output Verification Test

5 Verification and Performance Tests
Additional Verification Tests
170 U3606A User’s and Service Guide
Table 5 - 18 Square-wave duty cycle output verification test
Output duty cycle Output amplitude Range
Error from
nominal 1 year
50% @ 4800 Hz 30 V 30 V ±2.55 %
50% @ 4800 Hz 8 V 8 V ±2.55 %
