3. Operating Procedure
93
ML-2050A/2051A/2150A
Chapter 3 Laser Welding by Control Panel (PANEL CONTROL)
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
(1) Press the MENU key to display the STATUS screen.
When Pin No.23 (control switching) of the EXT.I/O (1) connector is put to an
open circuit, the external input signals are invalidated and "PANEL CONTROL" is
displayed in "-STATUS."
(2) Adjust the workpiece and output unit positions to set an appropriate work
distance (distance between the workpiece and the output position).
(3) Move the cursor to "BEAM-1" to "BEAM-3" (branch shutters 1 to 3) and press the
ON key to open the branch shutter to be used.
In this example, set "BEAM-1" to ON. Branch shutter 1 is opened and the
corresponding SHUTTER comes on.
⇒
For powersharing, set all the BEAMs to be used to ON to open all the branch
shutters.
(4) Move the cursor to "POSITION" and press the ON key to output guide light.
"POSITION" is displayed as ON and the red point of guide light is visible at the
laser light irradiation position. Laser light is irradiated at the red point position.
(5) Check the laser light irradiation position.
If the point to be worked deviates from the red point of guide light, adjust the
position by moving the output unit or workpiece.
-STATUS [PANEL CONTROL]

WATER 28˚C
BEAM-1:OFF RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:ON POSI.BLINK:OFF POSITION:OFF
-STATUS [PANEL CONTROL]

WATER 28˚C
BEAM-1:ON RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:OFF POSI.BLINK:OFF POSITION:OFF
-STATUS [PANEL CONTROL]

WATER 28˚C
BEAM-1:ON RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:ON POSI.BLINK:OFF POSITION:ON
