Overview DC Asterion Series
1-2 M330460-01 Rev A
• DC power simulation
• Commercial manufacturing and process control
• Research and development
• Automotive component and battery testing
• ATE applications
See Figure 1-2 for decoding the DC Asterion Series Model Number.
AST XXX (AR) - XXX D X C - E X X
SERIES
Asterion
UNIT OUTPUT VOLTAGE (VDC)
40 60
AUTO RANGE
Blank = Fixed Range
AR = Auto-Ranging
UNIT OUTPUT CURRENT (ADC)
42 28
85 56
125 83
PRODUCT FAMILY
D = DC
FORM FACTOR (U)
1 = 1U
UNIT INPUT VOLTAGE (VAC)
C = 90-145 VAC 1-ph, 180-264 VAC 1-ph/3-ph
D = 400 V 3-ph*
1
E = 480 V 3-ph*
FRONT PANEL
E = Enhanced
GPIB OPTIONS
0 = None
1 = GPIB
ADDITIONAL OPTIONS
0 = None
1 = Isolated Analog
Figure 1-2. Asterion DC Series Model Number Decoding
*
Consult factory for option
