Overview DC Asterion Series
2-2 M330460-01 Rev A
5. Protective cover for AC input, with fastening nuts (cover P/N 9330328-01R;
M4 nuts P/N MN-M04K-07, quantity one).
6. Hardware for output power:
• 1U, 1.7- 5 kW, 40V-60V models: M8 x 25 mm long bolt P/N MS-M08H-
4125, quantity two; Nut P/N 082019, quantity two; Washer, quantity four
P/N MW-M084-B; Lock washer, quantity four P/N 076022.
7. Protective cover for DC output, with fastening nuts (cover P/N 9330329-01R;
M4 nuts P/N MN-M04K-07, quantity two).
8. Rackmount flange bracket kit (P/N 5330241-01R, quantity two; includes four
M4 mounting screws P/N FM1001).
Note: If any of these parts are missing, contact AMETEK Customer Service
Department at 858-458-0223 (local) or 1-800-733-5427 (toll free).
Optional accessories:
1. 5330201-01R: Rackmount slide kit; includes two slides with rack adapter
brackets and mounting hardware.
2. 890-524-01: Paralleling/Series Cable*
(Requires two such cables to place one
unit in parallel/series with another).
2.3 Mechanical Installation
The Asterion DC Series power source is designed for rackmount applications, there is
an option for a rack mounted slide. Rack mounting requires installing the flange
brackets with handles to the side of the chassis: using M4-0.7 x 6 mm Philips flat-head
screws to mount the brackets to the chassis, and # 8-32 Philips flat-head screws to
mount the handles to the brackets.
The unit is forced-air cooled with internal fans drawing air in from the front and sides
and exhausting at the rear. The front and rear of the unit must be kept clear of
obstruction and clearance must be maintained to allow unimpeded airflow. The same
consideration given to the side grilles will minimize internal temperature rise. Special
consideration must be made to overall air flow characteristics, and the resultant
internal heat rise, when a source is installed inside enclosed cabinets to avoid
excessive heating and over-temperature problems. The temperature of the ambient
air at the air intake should not exceed 50°C.
