DC Asterion Series Overview
M330460-01 Rev A 3-7
Entry Description
SETTINGS
VOLTAGE Programs the output voltage in Volts.
Negative values can also be entered, refer to Figure 3-12.
Figure 3-12. Voltage Setting
CURRENT Programs the output current in Amperes. The default is full-scale
for the model, refer to Figure 3-13.
Figure 3-13. Current Setting
OVP Programs the Overvoltage Protection (OVP) threshold for the
output voltage. Exceeding the OVP threshold will result in
shutdown of the output and the output voltage programmed to
zero, refer to Figure 3-14.
Figure 3-14. OVP Setting
REGULATION Selects options for regulation of the output voltage: CC/CV/CP,
Constant Power, Constant Voltage and Constant Current. Also,
there is option to set the Delay interval, refer to Figure 3-15.
