Overview DC Asterion Series
1-4 M330460-01 Rev A
1-PH Input Connections
2 wires + ground, 264 VAC, Maximum Line-Neutral
3-PH Input Connections
3 wires + ground; delta configuration; 264 VAC, maximum line-to-line
Isolation Voltage
1500VAC primary to earth, 3000VAC on primary to SELV and Hazardous
secondary to SELV isolation barriers
THDV
≤1%
1)
Typical Value, at full load, with 200VAC Input voltage
2)
At full load and with 200VAC input voltage, 50/60 Hz input frequency
3)
Typical Value, At full load and with nominal AC input voltage, 50/60 Hz input frequency
1.2.3 Output Power derating characteristics with AC input Voltage
Output Power derating
characteristics with AC
input voltage
Model
Rated
Output
Power
1-Phase Low
Input Range
(90 -145 V AC)
1-Phase High
Input Range
(180-200VAC)
1-Phase High
Input Range
(200- 264 VAC)
3-Phase
(180 -264 VAC)
1U
1.7 kW
1.2 kW
1.7 kW
1.7 kW
1.7 kW
3.4 kW
1.2 kW
3.0kW
3.4 kW
3.4 kW
5.0 kW
1.7 kW
3.4kW
3.4 kW
5.0 kW
1.2.4 DC output programming and measurement specifications
PROGRAMMING & READBACK (FRONT PANEL OR REMOTE DIGITAL INTERFACE)
Voltage Output programming accuracy
+/- 0.1% of rated output voltage
Current Output programming accuracy
+/- 0.2% of rated output current
Power Output programming accuracy
+/- 0.3% of rated output power
Overvoltage programming accuracy
±1%, maximum, of rated output voltage
Voltage Output programming resolution
0.012% of full scale
Current Output programming resolution
0.012% of full scale
Power Output t programming resolution
0.012% of full scale
Overvoltage programming resolution
0.1% of full scale
Voltage Output readback accuracy
+/- 0.1% of rated output voltage
Current Output readback accuracy
+/- 0.2% of rated output current
Pout readback accuracy
+/- 0.3% of rated output power
Voltage Output readback resolution
0.012% of full scale
Current Output readback resolution
0.012% of full scale
Power Output readback resolution
0.012% of full scale
Overvoltage Response time
20 ms
1.2.5 DC output regulation Characteristics
Constant Voltage Mode
Maximum line regulation
+/- 0.01% of rated voltage
