Amoul i6 - Spo Monitoring Specifications

88
Average Heart
Rate
Comply with the requirements of YY 1079-2008 Part 4.1.2.1 d). The average
heart rate has been calculated as follows:
If the last three consecutive RR intervals are greater than 1200 ms, the 4
closest RR intervals are averaged to calculate heart rates. Otherwise, take the
12 closest RR intervals, subtract the maximum and minimum values, and take
the average to calculate the heart rate.
The heart rate value displayed on the screen is refreshed every second
Pulse
Identification
For PACE pulses that meet the following conditions, the PACE mark will appear
on the screen:
Amplitude: ± 2- ± 700 mV
Width: 0.1- 2 ms
Rise time: 10- 100 μs
Pacing
Suppression
Accord with the requirements of YY1079-2008 Part 4.1.4.1 and 4.1.4.3, pulses
that meet the following conditions are suppressed:
Amplitude: ± 2- ± 700 mV
Width: 0.1- 2 ms
Rise time: 10- 100 μs
Minimum input pendulum rate: 10 V/s RTI
21.6.2 SpO
2
Monitoring Specifications
SpO
2
Specifications
SpO
2
Measurement
Range
0 % - 100 %
SpO
2
Measurement
Accuracy
Between 0 and 69 %
Between 70 % and 100 %
Accuracy is not
predefined
± 2 % (adult/children), ± 3 % (neonate)
SpO
2
Measurement
Resolution
1 %
SpO
2
Alarm
Range
High limit alarm
Low limit alarm
Alarm error
SpO
2
low limit+ 2 %) to
100 %
0 % to (SpO
2
High limit-
2 %)
± 1 %
Emission
Wavelength
600- 1000 nm
Maximum
Optical Output
Power
<18 mW
