Amoul i6 - Productstructure and Function; Product Structure; Product Functions; Views

7
Symbol
Description
Symbol
Description
Environmental life of electronic products (20 years)
This product complies with the EUMDD 93/42/EEC and meets the basic
requirements of Annex I of the Directive, therefore bears the CE marking
2.4 ProductStructure and Function
2.4.1 Product Structure
The Defibrillator Monitor i6 consists of the main unit, battery, and pads (disposable pads for
both adult and pediatric patients).
2.4.2 Product Functions
There are four operating modes of the i6 defibrillator monitor: manual defibrillation, AED,
pacer and monitoring. In which, the monitoring module includes ECG monitoring, Resp
monitoring, SpO
2
monitoring, NIBP monitoring, Temp monitoring, and CO
2
monitoring.
2.4.3 Views
• Main Unit - Front View
2- 1 Front view
Num
ber
Parts
Description
1
Handle
Used for manual defibrillation to provide defibrillator discharge to
the patient.
