• Manual: perform an NIBP measurement manually when required.
• Auto: the Defibrillator Monitor automatically and repeatedly performs NIBP
measurements according to the set time interval.
10.5 Set initial Pressure
You can manually set the initial inflation pressure for the cuff.
Select the NIBP parameter area, open the [NIBP settings] menu, select [Initial Inflation
Pressure] and set the appropriate cuff pressure. At the next NIBP measurement, the cuff will be
inflated according to the set initial pressure.
The initial inflation pressure range is as follows:
Patient Category
Setting range (mmHg)
Step length
(mmHg)
Default (mmHg)
Adults
80-280
10
160
Children
80-210
140
Neonates
60-140
90
Caution:
 The initial inflation pressure cannot be set during NIBP measurement.
 After the NIBP module is reset or the patient category is changed, the initial
inflation pressure will revert to the default value of the current patient category.
