In manual defibrillation mode, the Defibrillator Monitor displays only one ECG waveform
and related parameters. The defibrillation information area in the middle of the screen displays
various related defibrillation information, such as defibrillation mode, synchronization identifier,
defibrillation energy, patient contact impedance indication, defibrillation prompt, and several
shocks.
Patient impedance high, paddle or pad disconnected
Paddle or pad cable disconnected
5- 2 Display of contact impedance
To turn on the contact impedance display, refer to 5.3 Manual Defibrillation settings.
Caution:
It is recommended that the patient be defibrillated when the contact impedance indication
is normal. Defibrillation can also be performed when the contact impedance is high.
5.3 Manual Defibrillation Settings
Information related to manual defibrillation can be set as follows:
1. Press the knob to bring up the [Menu] screen and select [General Configuration] -
[Manual Defibrillation]. The manual defibrillation settings screen is shown in the following figure.
5- 3 Manual defibrillation
